Web-managed industrial 10GbE switch
QNAP QSW-IM3216-8S8T Industrial Switch
A fanless, IP20-rated industrial switch with sixteen 10GbE ports, redundant DC power inputs and QSS web management for high-speed networks in demanding environments.
Managed 10GbE networking for industrial environments
The QNAP QSW-IM3216-8S8T combines eight SFP+ fibre ports and eight multi-speed RJ45 ports in a fanless, shock-resistant IP20 enclosure. QNAP Switch System provides graphical web management and practical Layer 2 controls, while redundant wide-voltage DC inputs support continuous operation across industrial, smart-city and AV-over-IP deployments.
Key features and benefits
Sixteen high-speed ports
Eight 10GbE SFP+ ports and eight multi-speed 10GbE RJ45 ports connect fibre and copper devices.
Industrial operating design
The fanless, IP20-rated enclosure is designed for shock resistance and wide-temperature operation.
Redundant wide-voltage power
Two DC 9–54V inputs, a circuit breaker and power-failure relay support resilient industrial power arrangements.
Graphical QSS management
The web interface provides an overview dashboard, port management, setup guides and online firmware checking.
Layer 2 traffic control
LACP, VLAN, QoS and IGMP Snooping provide bandwidth and packet-management options.
Security and resilience tools
ACL, LLDP, RSTP, Flow Control, SNMP and Qfinder Pro login support network administration.
Who is the QNAP QSW-IM3216-8S8T best for?
A strong choice for
- Factory automation and smart-manufacturing networks
- Smart-city and traffic-monitoring infrastructure
- AV-over-IP deployments with multiple endpoints
- Sites combining 10GbE fibre and multi-speed copper
- Rack, desktop or wall-mounted industrial installations
Consider another model if you need
- PoE or PoE+ power delivery to connected devices
- More than sixteen 10GbE ports
- An unmanaged switch with no configuration interface
- Operating requirements outside the supplied temperature and power ranges
Key specifications
- Network ports
- 8 × 10GbE SFP+ (10G/1G) and 8 × 10GbE RJ45 (10G/5G/2.5G/1G)
- Backplane bandwidth
- Up to 320Gbps
- Management
- QSS web management with Layer 2 functions
- Protection
- Fanless, shock-resistant, IP20-rated enclosure
- Power inputs
- 2 × DC 9–54V with redundancy and circuit breaker
- Operating temperature
- ?30°C to 65°C in airy environments (0.5–0.7m/s); ?30°C to 45°C in enclosed spaces
- Mounting
- Rack, desktop or wall mount
- Warranty
- 2 years; optional extension up to 5 years
Full technical specifications
Network management and system functions
| Traffic management | LACP, VLAN, QoS, IGMP Snooping |
|---|---|
| Security and system functions | ACL, LLDP, RSTP, Flow Control |
| Administration | QSS web interface, SNMP, Qfinder Pro login |
| AV-over-IP | IGMP Snooping and controlled traffic forwarding |
| Power-failure signalling | Power-failure relays can connect to alarms |
| Included power item | DC power adapter |
Frequently asked questions about the QNAP QSW-IM3216-8S8T
What is the QNAP QSW-IM3216-8S8T?
The QNAP QSW-IM3216-8S8T is a web-managed industrial switch with sixteen 10GbE ports, a fanless IP20 enclosure and redundant DC inputs.
Which ports are included?
It includes eight 10GbE SFP+ ports supporting 10G/1G and eight RJ45 ports supporting 10G/5G/2.5G/1G.
How is the QNAP QSW-IM3216-8S8T managed?
It uses QNAP Switch System, a graphical web interface for dashboard monitoring, port management and Layer 2 configuration.
Can the QNAP QSW-IM3216-8S8T operate in high temperatures?
The supplied description states ?30°C to 65°C in airy environments with 0.5–0.7m/s airflow, or ?30°C to 45°C in enclosed spaces.
Does the switch have redundant power?
Yes. It provides two DC 9–54V power inputs with redundancy and a circuit breaker.
What installation options are supported?
The switch can be rack mounted, placed on a desktop or wall mounted.
What warranty is supplied?
The QNAP QSW-IM3216-8S8T has a 2-year warranty, with an optional extension up to 5 years.
