IronWolf is purpose-built for NAS systems. Rely on 24×7, robust, accessible and scalable performance at all times, designed for multi-bay environments and varying capacities.
- Powerful NAS hard drive.
- Higher capacity drives have rotational speeds of up to 7200 RPM, sustained transfer speeds of up to 180 MB/s, and burst data transfer speeds of 6 Gb/s.
- IronWolf Health Management for monitoring drive health on compatible NAS systems.
- Workload rates up to 180 TB/year and optional hard drive data recovery.
- Suitable for 1-bay to 8-bay Network-Attached Storage (NAS) servers, home media servers, personal clouds, small offices and workstations.
Specification
Capacity: 12 TB
Dimensions: W x H x D 26.11mm/1.028in × 101.85mm/4.01in × 146.99mm/5.787in
Weight: 690g/1.521lb
| Specifications | 12TB |
|---|---|
| Capacity | 12TB |
| Standard Model Number | ST12000VN0008 |
| Interface | SATA 6Gb/s |
| Drive Bays Supported | 1-8 Bays |
| Multi-User Technology | 180TB/year |
| Rotational Vibration Sensor | Yes |
| Dual-Plane Balance | Yes |
| Error Recovery Control | Yes |
| Max Sustained Transfer Rate (MB/s) | 210MB/s |
| Spindle Speed (RPM) | 7200 |
| Cache (MB) | 256 |
| Load/Unload Cycles | 600,000 |
| Nonrecoverable Read Errors Rate | 1 per 10E15 |
| Power-On Hours | 8,760 |
| Workload Rate Limit (WRL) | 180 |
| MTBF (hours) | 1,000,000 |
| Limited Warranty (years) | 3 |
| Startup Current (12V, A) | 1.8 |
| Average Operating Power (W) | 7.8W |
| Idle Power (W) | 5W |
| Standby/Sleep Power (W) | 0.8/0.8 |
| Voltage Tolerance (5V) | ±5% |
| Voltage Tolerance (12V) | ±10% |
| Operating Temp (min °C) | 5 |
| Operating Temp (max °C) | 70 |
| Non-Operating Temp (min °C) | -40 |
| Non-Operating Temp (max °C) | 70 |
| Halogen Free | Yes |
| Shock (Operating/Non-Operating Gs) | 70/250 |
| Acoustics (Idle, bels) | 1.8 |
| Acoustics (Seek, bels) | 2.8 |
| Height (mm/in) | 26.11mm/1.028in |
| Width (mm/in) | 101.85mm/4.01in |
| Depth (mm/in) | 146.99mm/5.787in |
| Weight (g/lb) | 690g/1.521lb |
| Carton Unit Quantity | 20 |
| Cartons per Pallet / Layer | 40/8 |
