Versatile and scalable storage
Flexible storage with redundancy
Over 3,519/1,790 MB/s seq. read/write , built-in 10GbE, and up to 560 TB raw storage after expansion
Flexible configuration
Add 12 extra drive bays, 10/25GbE ports, and SSD cache volumes whenever needed
Versatile applications
Back up endpoints, manage up to 90 IP cameras, or safely sync and share files across sites
Specification
CPU |
CPU Model | AMD Ryzen V1780B |
---|---|---|
CPU Quantity | 1 | |
CPU Core | 4 | |
CPU Architecture | 64-bit | |
CPU Frequency | 3.35 (base) / 3.6 (turbo) GHz | |
Hardware Encryption Engine |
|
|
Memory |
System Memory | 8 GB DDR4 ECC UDIMM |
Memory Module Pre-installed | 8 GB (8 GB x 1) | |
Total Memory Slots | 2 | |
Maximum Memory Capacity | 32 GB (16 GB x 2) | |
Notes |
|
|
Storage |
Drive Bays | 16 |
Maximum Drive Bays with Expansion Unit | 28 (RX1225RP x 1) | |
Drive Type |
|
|
Hot Swappable Drive* |
|
|
Notes | Compatible drives are mandatory. Please consult our before purchasing hard drives. For more details, please refer to | |
External Ports |
RJ-45 1GbE LAN Port | 2 |
RJ-45 10GbE LAN Port | 1 | |
USB 3.2 Gen 1 Port | 2 | |
Expansion Port | 1 | |
Expansion Port Type | Mini-SAS HD | |
Notes | This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes. | |
PCIe |
PCIe Expansion | 1 x Gen3 x8 slot (x4 link) |
Appearance |
Form Factor (RU) | 3U |
Size (Height x Width x Depth) | 132.3 mm x 482 mm x 656.5 mm | |
Weight | 17.3 kg | |
Rack Installation Support* | 4-post 19" rack (Synology Rail Kit - ) | |
Notes | The rail kit is sold separately | |
Others |
System Fan | 80 mm x 80 mm x 3 pcs |
Fan Speed Mode |
|
|
Easy Replacement System Fan |
|
|
Power Recovery |
|
|
Noise Level* | 49.6 dB(A) | |
Scheduled Power On / Off |
|
|
Wake on LAN / WAN |
|
|
Power Supply Unit / Adapter | 550 watts | |
Redundant Power Supply |
|
|
AC Input Power Voltage | 100 V to 240 V AC | |
Power Frequency | 50/60 Hz, Single Phase | |
Power Consumption* | 134.48 watts (Access) 50.81 watts (HDD Hibernation) |
|
British Thermal Unit | 459.17 BTU/hr (Access) 173.49 BTU/hr (HDD Hibernation) |
|
Notes |
|
|
Temperature |
Operating Temperature | 0°C to 35°C (32°F to 95°F) |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
Operating Humidity | 8% to 80% RH | |
Storage Humidity | 5% to 95% RH | |
Certification |
|
|
Warranty |
3-year hardware warranty, extendable to 5 years | |
Notes |
|
|
Environment |
RoHS Compliant | |
Packaging Content |
|
