Build a plug-and-play video wall
Optimized for video walls
Scale your TV wall with up to 50 video streams across two screens
Crystal-clear video feeds
Watch live camera feeds in up to 4K resolution
Plug-and-play surveillance
Experience instant access to Surveillance Station
US regulatory compliance
NDAA and TAA compliance help meet US federal requirements
Specification
|
Hardware Specifications
|
||
|---|---|---|
|
Video Outputs
|
Video Outputs | HDMI x 2 |
| Supported Video Resolution |
|
|
|
Audio Input
|
3.5 mm Stereo Audio Jack x 1 | |
|
Audio Output
|
3.5 mm Stereo Audio Jack x 1 | |
|
RJ-45 1GbE LAN Port
|
1 | |
|
USB 3.0 Port
|
2 | |
|
Appearance
|
Size (Height x Width x Depth) | 41.84 mm x 150 mm x 150 mm |
| Weight | 0.36 kg | |
|
Others
|
Power Supply Unit / Adapter | 36 W |
| AC Input Power Voltage | 100 V to 240 V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption | 15.49 W (50ch full-load) 5.85 W (Power on Idle) |
|
|
Temperature
|
Operating Temperature | -20°C to 40°C (-4°F to 104°F) |
| Adapter Operating Temperature | 0°C to 40°C (32°F to 104°F) | |
| Operating humidity | 8% to 80% RH | |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
|
Certification
|
|
|
|
NDAA compliance
|
||
|
TAA compliance
|
||
|
Warranty
|
3 Years | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. | |
|
Environment
|
RoHS Compliant | |
|
Packaging Content
|
|
|
