Samsung PM893 960GB 2.5" SATA 6GB/s V-NAND SSD - MZ7L3960HCJR-00W07 - OEM
Regular price
$352.58
Sold Out
GST Included
Adding product to your cart
960GB enterprise 2.5-inch SATA data-centre SSD
Samsung PM893 960GB MZ7L3960HCJR-00W07 Enterprise SATA SSD
The Samsung PM893 960GB MZ7L3960HCJR-00W07 is a 2.5-inch SATA 6Gb/s enterprise SSD rated up to 550/520MB/s sequential read/write, 98K/30K random read/write IOPS and 1,752TBW for data-centre and server storage.
- 960GB capacity
- 550/520MB/s
- 98K/30K IOPS
- 1,752TBW
- AES 256-bit + TCG Opal 2.0
- 5-year limited warranty
| Capacity |
960GB |
| Performance |
Up to 550/520MB/s read/write |
| Interface |
SATA 6Gb/s |
| Endurance |
1,752TBW |
Consistent SATA storage for data-centre and server workloads
The Samsung PM893 960GB MZ7L3960HCJR-00W07 combines Samsung V-NAND TLC, enterprise endurance and end-to-end data protection in a standard 7mm 2.5-inch form factor. Its exact 960GB profile includes 30K random-write IOPS, 2.2/3.2W average active read/write power and a five-year limited warranty.
550/520MB/s sequential
Samsung rates the 960GB model up to 550MB/s sequential read and 520MB/s sequential write.
98K/30K random IOPS
The exact capacity profile reaches up to 98K random-read and 30K random-write IOPS at QD32.
1,752TBW endurance
Samsung specifies 1,752TBW for the 960GB PM893 under its enterprise endurance profile.
Enterprise data protection
The PM893 is positioned for data-centre and server use with end-to-end data protection.
Built-in data security
Samsung lists AES 256-bit full-disk encryption, TCG Opal 2.0 and IEEE1667 Encrypted Drive support.
Five-year warranty
Samsung specifies a five-year limited warranty, with coverage governed by the stated period or TBW terms.
Who is the Samsung PM893 960GB MZ7L3960HCJR-00W07 best for?
A strong choice for
- Compatible server and data-centre SATA bays
- Read-intensive enterprise storage
- Virtualisation and infrastructure workloads within the drive profile
- Systems requiring enterprise SATA security features
- Deployments needing 960GB nominal capacity and high endurance
Consider another model if you need
- You require NVMe or PCIe performance
- You need a consumer retail drive with retail packaging
- Your platform does not support a 2.5-inch 7mm SATA SSD
- Your workload requires endurance above 1,752TBW
Key specifications
| Official part number |
MZ7L3960HCJR-00W07 |
| Capacity |
960GB |
| Application |
Data centre and server |
| Form factor |
2.5-inch, 7mm |
| Interface |
SATA 6Gb/s |
| NAND |
Samsung V-NAND TLC |
| Sequential read/write |
Up to 550/520MB/s |
| Random read/write |
Up to 98K/30K IOPS |
| Endurance |
1,752TBW |
| MTBF |
2,000,000 hours |
| Data security |
AES 256-bit, TCG Opal 2.0, IEEE1667 |
| Warranty |
Five-year limited |
Full technical specifications
Hardware and performance
| Series |
Samsung PM893 |
| Official part number |
MZ7L3960HCJR-00W07 |
| Capacity |
960GB |
| Application |
Data centre and server |
| Form factor |
2.5-inch |
| Drive height |
7mm |
| Interface |
SATA 6Gb/s |
| SATA compatibility |
SATA 3Gb/s and 1.5Gb/s |
| Controller |
Samsung in-house controller |
| NAND flash |
Samsung V-NAND TLC |
| Sequential read |
Up to 550MB/s |
| Sequential write |
Up to 520MB/s |
| 4KB random read, QD32 |
Up to 98K IOPS |
| 4KB random write, QD32 |
Up to 30K IOPS |
Power, reliability and endurance
| Idle power, DIPM off |
1.5 W |
| Average active read power |
2.2 W |
| Average active write power |
3.2 W |
| Operating temperature |
0°C to 70°C |
| Non-operating temperature |
-40°C to 85°C |
| Humidity |
5% to 95% non-condensing |
| Non-operating shock |
1,500G for 0.5ms, three axes |
| Non-operating vibration |
20–2,000Hz, 20G |
| MTBF |
2,000,000 hours |
| Endurance |
1,752TBW |
| Warranty |
Five-year limited |
Physical details, features and security
| Dimensions |
100.2 × 69.85 × 7mm |
| TRIM |
Supported; OS support required |
| Garbage Collection |
Supported |
| S.M.A.R.T. |
Supported |
| Encryption |
AES 256-bit full-disk encryption |
| Security standard |
TCG Opal 2.0 |
| Encrypted Drive |
IEEE1667 |
| Packaging |
OEM drive; no retail packaging stated in the supplied listing |
| Nominal capacity note |
Actual usable capacity may be lower |
Frequently asked questions about the Samsung PM893 960GB MZ7L3960HCJR-00W07
What is the Samsung PM893 960GB MZ7L3960HCJR-00W07?
It is a 960GB enterprise 2.5-inch SATA SSD designed for data-centre and server applications.
What sequential speed does the MZ7L3960HCJR-00W07 provide?
Samsung rates it up to 550MB/s read and 520MB/s write.
What random performance applies to the MZ7L3960HCJR-00W07?
The 960GB profile is rated up to 98K random-read and 30K random-write IOPS at QD32.
What endurance applies to the MZ7L3960HCJR-00W07?
Samsung specifies 1,752TBW for the 960GB capacity.
Does the MZ7L3960HCJR-00W07 support encryption?
Yes. Samsung lists AES 256-bit full-disk encryption, TCG Opal 2.0 and IEEE1667 Encrypted Drive.
What interface does the MZ7L3960HCJR-00W07 use?
It uses SATA 6Gb/s and is compatible with SATA 3Gb/s and 1.5Gb/s interfaces.
What are the MZ7L3960HCJR-00W07 dimensions?
It measures 100.2 × 69.85 × 7mm in a 2.5-inch form factor.
What power figures apply to the 960GB MZ7L3960HCJR-00W07?
Samsung lists 1.5W idle, 2.2W average active read and 3.2W average active write power.
Does this MZ7L3960HCJR-00W07 include retail packaging?
The supplied listing identifies it as an OEM drive without retail packaging.
What warranty applies to the MZ7L3960HCJR-00W07?
Samsung specifies a five-year limited warranty; coverage is subject to the stated warranty and endurance terms.
Important information:
- This is an enterprise data-centre/server SSD; confirm platform, firmware and management compatibility before deployment.
- The supplied listing identifies the drive as OEM with no retail packaging.
- Performance varies with workload, host and test conditions.
- Actual usable capacity may be lower than the labelled capacity.
