Samsung 980 Pro 1TB M.2 NVMe SSD with Heatsink for PS5
Regular price
$217.16
Sold Out
GST Included
Adding product to your cart
1TB M.2 2280 NVMe client SSD with heatsink
Samsung 980 PRO 1TB MZ-V8P1T0CW M.2 NVMe SSD with Heatsink
The Samsung 980 PRO 1TB MZ-V8P1T0CW is a 1TB M.2 2280 client SSD rated up to 7,000MB/s sequential read and 5,000MB/s sequential write, with 1,000K IOPS/1,000K IOPS QD32 random read/write performance and 600TBW endurance.
- 1TB
- 7,000MB/s/5,000MB/s
- 1,000K IOPS/1,000K IOPS
- PCIe 4.0 x4
- 600TBW
- 5-year limited warranty
| Capacity |
1TB |
| Sequential performance |
Up to 7,000MB/s read; 5,000MB/s write |
| Interface |
PCIe Gen 4.0 x4 |
| Endurance |
600TBW |
980 PRO performance for compatible client systems
The Samsung 980 PRO 1TB MZ-V8P1T0CW combines Samsung V-NAND, an in-house controller and the PCIe Gen 4.0 x4 interface in a compact M.2 2280 format. Its capacity-specific performance, cache design, endurance and thermal configuration are stated separately so buyers can match the exact SKU to a supported system.
Up to 7,000MB/s read
Samsung rates this exact 1TB model up to 7,000MB/s sequential read under its published test conditions.
Up to 5,000MB/s write
The capacity-specific sequential write rating is up to 5,000MB/s with the supported write-acceleration feature active.
1,000K IOPS/1,000K IOPS random IOPS
QD32 random performance is rated up to 1,000K IOPS read and 1,000K IOPS write for this exact capacity.
LPDDR4 DRAM cache
Samsung pairs the in-house controller with capacity-specific LPDDR4 cache memory for the 980 PRO.
600TBW endurance
Samsung specifies 600TBW for this capacity, with warranty coverage governed by the stated period or endurance limit.
Factory-fitted heatsink
The integrated heatsink is designed to help manage drive temperature; Samsung states that it must not be removed.
Who is the Samsung 980 PRO 1TB MZ-V8P1T0CW best for?
A strong choice for
- Compatible desktop and workstation storage upgrades
- Supported client-PC boot and application drives
- Gaming, creative and productivity workloads within the published profile
- Users needing 1TB nominal capacity
- Buyers who want Samsung Magician management support
Consider another model if you need
- Your system lacks a compatible M.2 2280 NVMe slot
- You require performance beyond 7,000MB/s/5,000MB/s
- You need a data-centre or enterprise endurance profile
- Your host cannot accommodate the published heatsink dimensions
Key specifications
| Official model code |
MZ-V8P1T0CW |
| Capacity |
1TB |
| Usage application |
Client PCs |
| Form factor |
M.2 2280 |
| Interface |
PCIe Gen 4.0 x4 |
| NVMe version |
NVMe 1.3c |
| NAND |
Samsung V-NAND 3-bit MLC |
| Cache |
1GB LPDDR4 |
| Sequential read/write |
Up to 7,000MB/s/5,000MB/s |
| QD32 random read/write |
Up to 1,000K IOPS/1,000K IOPS |
| Endurance |
600TBW |
| Dimensions |
Maximum 80.15 × 25 × 8.88 mm |
| Warranty |
Five years limited or TBW, whichever comes first |
Full technical specifications
Hardware and performance
| Series |
Samsung 980 PRO |
| Official model code |
MZ-V8P1T0CW |
| Capacity |
1TB |
| Usage application |
Client PCs |
| Form factor |
M.2 2280 |
| Interface |
PCIe Gen 4.0 x4 |
| NVMe version |
NVMe 1.3c |
| Controller |
Samsung in-house controller |
| NAND flash memory |
Samsung V-NAND 3-bit MLC |
| Cache memory |
1GB LPDDR4 |
| Sequential read |
Up to 7,000MB/s |
| Sequential write |
Up to 5,000MB/s |
| Random read, 4KB QD32 |
Up to 1,000K IOPS |
| Random write, 4KB QD32 |
Up to 1,000K IOPS |
| Random read, 4KB QD1 |
Up to 22K IOPS |
| Random write, 4KB QD1 |
Up to 60K IOPS |
Physical, power and reliability
| Dimensions |
Maximum 80.15 × 25 × 8.88 mm |
| Heatsink configuration |
Factory-fitted heatsink |
| Average active read power |
6.2W |
| Average active write power |
5.7W |
| Idle power |
35mW (APST on) |
| Low-power mode |
5mW (L1.2) |
| Operating temperature |
0°C to 70°C |
| Non-operating temperature |
-40°C to 85°C |
| Humidity |
5% to 95% non-condensing |
| Non-operating shock |
1,500G, 0.5ms, 3 axis |
| Non-operating vibration |
20 to 2,000Hz, 20G |
| MTBF |
1.5 million hours |
| Cooling guidance |
Keep the pre-installed heatsink attached and confirm host clearance |
Features, security and warranty
| TRIM |
Supported; operating-system support required |
| Garbage collection |
Supported |
| S.M.A.R.T. |
Supported |
| Write acceleration |
Samsung Intelligent TurboWrite |
| Management software |
Samsung Magician Software |
| AES full-disk encryption |
256-bit |
| TCG Opal |
Version 2.0 |
| Encrypted Drive |
IEEE1667 |
| Endurance |
600TBW |
| Warranty period |
Five years limited |
| Warranty basis |
Five years or 600TBW, whichever comes first |
| Performance condition |
Varies with firmware, host hardware, software and configuration |
| Nominal capacity note |
Actual usable capacity is lower after formatting and system use |
Frequently asked questions about the Samsung 980 PRO 1TB MZ-V8P1T0CW
What is the Samsung 980 PRO 1TB MZ-V8P1T0CW?
It is a 1TB M.2 2280 NVMe SSD designed for compatible client-PC workloads.
How fast is the MZ-V8P1T0CW?
Samsung rates it up to 7,000MB/s sequential read and 5,000MB/s sequential write; actual performance varies by system and workload.
What random performance does the MZ-V8P1T0CW provide?
Samsung specifies up to 1,000K IOPS QD32 random read and 1,000K IOPS QD32 random write for this exact capacity.
What interface does the MZ-V8P1T0CW use?
It uses PCIe Gen 4.0 x4 with NVMe 1.3c.
Does the MZ-V8P1T0CW have dedicated DRAM?
Yes. Samsung specifies capacity-specific LPDDR4 DRAM cache for the 980 PRO.
What endurance applies to the MZ-V8P1T0CW?
Samsung specifies 600TBW for this exact model.
What security features does the MZ-V8P1T0CW support?
Samsung lists AES 256-bit full-disk encryption, TCG Opal 2.0 and IEEE1667 Encrypted Drive.
Does the MZ-V8P1T0CW include a heatsink?
Yes. This CW model has a factory-fitted heatsink that Samsung states must not be removed.
What are the dimensions of the MZ-V8P1T0CW?
Samsung publishes maximum dimensions of 80.15 × 25 × 8.88 mm.
What warranty applies to the MZ-V8P1T0CW?
Samsung specifies five years limited or 600TBW, whichever comes first, subject to its warranty terms.
Important information:
- Confirm M.2 2280 support, PCIe Gen 4.0 x4 compatibility, physical clearance and cooling before purchase.
- Published performance is an up-to figure and varies with firmware, host hardware, software, workload and configuration.
- Do not remove the pre-installed heatsink; Samsung states removal can damage the drive and void the product warranty.
- The source positions this model for compatible PC and PlayStation 5 installations; confirm the host's current M.2 requirements, available space and firmware before purchase.
- Actual usable capacity is lower than the labelled capacity after formatting and system use.
