8-Port 2.5GbE Desktop Unmanaged Switch
QNAP QSW-1108-8T Unmanaged Switch
A fanless desktop unmanaged switch with eight 2.5GbE RJ45 ports, automatic loop detection and a stated switching capacity of 40Gbps.
An easy eight-port upgrade for 2.5GbE devices
The QNAP QSW-1108-8T provides eight 2.5GbE RJ45 ports in a compact fanless chassis. Plug-and-play setup, existing-cable positioning and automatic loop detection make it a straightforward way to connect compatible 2.5GbE NAS systems, computers and other network devices at home or in a small business.
Key features and benefits
Eight 2.5GbE RJ45 ports
Eight copper interfaces provide 2.5 Gigabit Ethernet connectivity.
Existing-cable positioning
The product is designed to enable 2.5GbE upgrades without requiring new network cabling.
Fanless cooling
The fanless design supports quiet desktop operation.
Plug-and-play setup
The unmanaged switch requires no network configuration.
Loop detection and blocking
Automatic loop protection supports continuous network operation.
Compact desktop chassis
The 27 × 240 × 105 mm design suits desks and small network spaces.
Who is this model best for?
A strong choice for
- 2.5GbE NAS and computer connections
- Quiet home and small-business networks
- Eight-port desktop deployments
- Plug-and-play network upgrades
- Networks using compatible existing cabling
Consider another model if you need
- You need 10GbE connectivity
- You require web or Layer 2 management
- You require Power over Ethernet
Key specifications
- Management type
- Unmanaged
- Ports
- 8 × 2.5GbE RJ45
- MAC address table
- 16K
- Non-blocking throughput
- 20Gbps
- Switching capacity
- 40Gbps
- Cooling
- Fanless
- Maximum power consumption
- 18W
- Form factor
- Desktop
- Dimensions
- 27 × 240 × 105 mm
- Warranty
- 2 Years
Full technical specifications
Network, ports and switching
| Management Type | Unmanaged |
|---|---|
| Number of Ports | 8 |
| 2.5GbE (RJ45) | 8 |
| MAC Address Table | 16K |
| Total Non-Blocking Throughput | 20Gbps |
| Switching Capacity | 40Gbps |
| Supported Standards | IEEE 802.3 Ethernet IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3bz 2.5GBase-T IEEE 802.3x Full-Duplex Flow Control |
| Jumbo Frames | 12K |
Physical, environmental and power
| Power Supply Description | Adapter |
|---|---|
| Max. Power Consumption | 18W |
| Input Power Type | DC |
| Fanless | Supported |
| Form Factor | Desktop |
| LED Indicators | Per Port: Speed/Link/Activity Loop LED: Loop Per System: Power/Status |
| Dimensions (HxWxD) | 27 x 240 x 105 mm |
| Weight (Net) | 0.639 kg |
| Weight (Gross) | 0.99 kg |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Relative Humidity | 5~90% Non-condensing |
Software and system features
| Input Voltage Range | 12V/1.5A |
|---|
Warranty and certifications
| Certifications | FCC, CE, BSMI, VCCI, LVD,CCC,KCC, UKCA |
|---|---|
| Electromagnetic Compliance | Class B |
| Warranty | 2 Years |
Frequently asked questions about the QSW-1108-8T
What is the QNAP QSW-1108-8T?
It is a fanless desktop unmanaged switch with eight 2.5GbE RJ45 ports.
How many ports does the QSW-1108-8T have?
It has eight 2.5GbE RJ45 data ports.
Which high-speed connections does the QSW-1108-8T provide?
All eight data ports provide 2.5 Gigabit Ethernet connectivity.
How is the QSW-1108-8T managed?
It is unmanaged and designed for plug-and-play operation without a web management interface.
What is the switching capacity of the QSW-1108-8T?
The stated switching capacity is 40Gbps.
What is the non-blocking throughput of the QSW-1108-8T?
The stated total non-blocking throughput is 20Gbps.
What form factor does the QSW-1108-8T use?
The QSW-1108-8T uses a desktop form factor.
What are the dimensions of the QSW-1108-8T?
The stated dimensions are 27 × 240 × 105 mm.
What warranty is provided with the QSW-1108-8T?
The QSW-1108-8T includes a two-year warranty.
Which network features are highlighted for the QSW-1108-8T?
It highlights fanless operation, plug-and-play setup and automatic loop detection and blocking.
Important information
The product is positioned for 2.5GbE upgrades using existing network cabling.
The product includes a two-year warranty.
