10GbE and 2.5GbE Desktop Unmanaged Switch
QNAP QSW-2104-2T Unmanaged Switch
A fanless desktop unmanaged switch with two 10GbE Multi-Gigabit RJ45 ports, additional 2.5GbE RJ45 connectivity and a stated switching capacity of 60Gbps.
Multi-Gigabit copper connectivity with quiet plug-and-play operation
The QNAP QSW-2104-2T combines two five-speed 10GbE copper ports with 2.5GbE access connectivity in a fanless desktop design. Plug-and-play setup, auto-negotiation and automatic loop detection support straightforward high-speed network upgrades for home and workplace devices.
Key features and benefits
Two 10GbE RJ45 ports
Two copper ports support 10G, 5G, 2.5G, 1G and 100M speeds.
2.5GbE access connectivity
Additional RJ45 connections support 2.5G, 1G and 100M speeds.
Fanless cooling
The ventilated fanless design supports quiet operation.
Plug-and-play setup
No switch configuration is required for deployment.
Automatic negotiation
Connected devices can negotiate the appropriate link speed.
Loop detection and blocking
Automatic loop protection supports continuous network operation.
Who is this model best for?
A strong choice for
- Copper-only Multi-Gigabit networks
- Quiet home and workplace deployments
- 10GbE NAS and workstation links
- 2.5GbE device connectivity
- Plug-and-play network upgrades
Consider another model if you need
- You need fibre SFP+ connections
- You require web or Layer 2 management
- You require Power over Ethernet
Key specifications
- Management type
- Unmanaged
- 10GbE interfaces
- 2 × BASE-T RJ45
- 10GbE supported speeds
- 10G / 5G / 2.5G / 1G / 100M
- MAC address table
- 16K
- Non-blocking throughput
- 30Gbps
- Switching capacity
- 60Gbps
- Cooling
- Fanless
- Maximum power consumption
- 12W
- Dimensions
- 34 × 180 × 145 mm
- Warranty
- 2 Years
Full technical specifications
Network, ports and switching
| Management Type | Unmanaged |
|---|---|
| 10GbE BASE-T (RJ45) | 2 |
| MAC Address Table | 16K |
| Total Non-Blocking Throughput | 30Gbps |
| Switching Capacity | 60Gbps |
| Supported Standards | IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3bz 2.5G/5GBase-T IEEE 802.3an 10GBase-T |
| Jumbo Frames | 9K |
Physical, environmental and power
| Power Supply Description | Adapter |
|---|---|
| Max. Power Consumption | 12W |
| Input Power Type | DC |
| Fanless | Supported |
| Form Factor | Desktop |
| LED Indicators | Per Port: Speed/Link/Activity Loop LED: Loop Per System: Power/Status |
| Dimensions (HxWxD) | 34 x 180 x145 mm |
| Weight (Net) | 0.722 kg |
| Weight (Gross) | 1.02 kg |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Relative Humidity | 5~90% Non-condensing |
Software and system features
| Input Voltage Range | 12V/1A |
|---|
Warranty and certifications
| Certifications | FCC, CE, BSMI, VCCI, LVD,CCC,KCC |
|---|---|
| Electromagnetic Compliance | Class B |
| Warranty | 2 Years |
Frequently asked questions about the QSW-2104-2T
What is the QNAP QSW-2104-2T?
It is a fanless desktop unmanaged switch combining 10GbE Multi-Gigabit RJ45 and 2.5GbE RJ45 connectivity.
How many 10GbE ports does it provide?
It provides two 10GbE BASE-T RJ45 ports.
Which speeds do the 10GbE RJ45 ports support?
They support 10G, 5G, 2.5G, 1G and 100M speeds.
Is it managed?
No. The QSW-2104-2T is an unmanaged plug-and-play switch.
Does it support loop protection?
Yes. Automatic loop detection and blocking are included.
Is it fanless?
Yes. It uses a fanless desktop design.
What is its switching capacity?
The stated switching capacity is 60Gbps.
What is its maximum power consumption?
The stated maximum power consumption is 12W.
What are its dimensions?
The stated dimensions are 34 × 180 × 145 mm.
What warranty is provided?
The QSW-2104-2T includes a two-year warranty.
Important information
The 10GbE RJ45 ports support 10G, 5G, 2.5G, 1G and 100M speeds.
The product includes a two-year warranty.
