Purpose-built for bulk data applications and intensive workloads.
- AFFORDABLE AND RELIABLE: With support for up to 10TB per drive, the Exos 7E10 provides mass data storage for data center infrastructures requiring highly reliable, enterprise-grade hard drives.
- ROBUST PERFORMANCE, 24×7: Exos 7E10 hard drives are backed by a 2M hour MTBF rating and capable of handling workloads of 550TB per year. Advanced caching, on-the-fly error correction algorithms, and vibration tolerance help ensure consistent performance in replicated and multi-drive RAID systems.
- EASE OF INTEGRATION, OPTIMAL TCO: Meet storage workload requirements in the most efficient and cost-effective data center form factor available today. The Exos 7E10 easily integrates into mass storage systems with 12Gb/s SAS and SATA 6Gb/s interface options.
- ADVANCED SECURITY FEATURES: Exos 7E10 prevents unauthorized drive access and keeps stored data safe Seagate Secure™ drives simplify drive reuse and retrieval, protect data at rest, and help meet federal and corporate data security requirements.
- RELIABLE EXPERTISE: With over 350 million enterprise drives sold since 2002 and our 5-year limited warranty, Seagate is a trusted leader in data storage solutions.
Specification
Capacity: 10 TB
Dimensions: W x H x D 26.11mm/1.028in × 101.85mm/4.010in × 147.0mm/5.787in
Weight: 720g/1.59lb
| Specifications | 10 TB |
|---|---|
| Standard | ST10000NM017B |
| FEATURES | |
| Protection Information (T10 DIF) | — |
| SuperParity | Yes |
| Low Halogen | Yes |
| PowerChoice™ Technology | Yes |
| PowerBalance Technology | Yes |
| Cache, Multi-segmented (MB) | 256 |
| Advanced Write Caching (8M internal NOR flash) | Yes |
| RELIABILITY/DATA INTEGRITY | |
| Vibration, Non-operating: 10 Hz to 500 Hz (Grms) | 5 |
| Mean Time Between Failures (MTBF, hours) | 2,000,000 |
| Reliability Rating @ Full 24×7 Operation (AFR) | 0.44% |
| Non-recoverable Read Errors per Bits Read | 1 sector per 10E15 |
| Power-On Hours per Year | 8,760 |
| Bytes per Sector | 512 |
| Warranty, Limited (years) | 5 |
| PERFORMANCE | |
| Spindle Speed (RPM) | 7,200 |
| Interface Access Speed (Gb/s) | 6.0, 3.0, 1.5 |
| Max. Sustained Transfer Rate OD | 263MB/s |
| Average Latency (ms) | 4.16 |
| Interface Ports | Single |
| Rotational Vibration @ 1,500 Hz (rad/s²) | 12.5 |
| POWER CONSUMPTION | |
| Idle Power, Average (W) | 7.8 |
| Typical Operating, Random Read (W) | 11.8 |
| Power Supply Requirements | +12 V and +5 V |
| ENVIRONMENTAL | |
| Temperature, Operating (°C) Drive Reported | 5 ~ 60 |
| Shock, Operating 2 ms Read/Write (Gs) | 70/40 Gs |
| Shock, Non-operating, (1 ms/2 ms) (Gs) | 150/300 |
| PHYSICAL | |
| Height (in/mm, max) | 1.028 in/26.11 mm |
| Width (in/mm, max) | 4.01 in/101.85 mm |
| Depth (in/mm, max) | 5.787 in/147 mm |
| Weight (lb/g) | 720 g/1.59 lb |
| Carton Unit Quantity | 20 |
| Cartons per Pallet / Cartons per Layer | 40/8 |
