2-bay personal NAS
ASUSTOR Drivestor AS3302T-V2
The ASUSTOR Drivestor AS3302T-V2 is a 2-bay NAS with Realtek RTD1619B, Quad-Core 1.7GHz, 2GB DDR4 and 1x 2.5 Gigabit Ethernet (2.5G/1G/100M).
- Processor
- Realtek RTD1619B — Quad-Core 1.7GHz
- Memory
- 2GB DDR4
- Drive bays
- 2
- Networking
- 1x 2.5 Gigabit Ethernet (2.5G/1G/100M)
Straightforward NAS storage based on the supplied feature set
The supplied Drivestor AS3302T V2 description positions this two-bay NAS as an affordable personal cloud for individuals and families. It lists a Realtek RTD1619B quad-core processor, 2GB DDR4 memory, 2.5-Gigabit Ethernet, Wake-on-LAN/WAN, Btrfs/iSCSI snapshots, tool-free installation and 4K video transcoding.
Personal-cloud positioning
The supplied description is written for individuals and families looking for centralised personal storage.
Realtek quad-core processor
The exact hardware table lists Realtek RTD1619B with Quad-Core 1.7GHz.
Fixed 2GB DDR4 memory
The supplied table lists 2GB DDR4 and states memory is not expandable.
Two SATA drive bays
The exact table lists 2 drive bays and the supplied compatible-drive types.
2.5GbE networking
The exact hardware table lists 1x 2.5 Gigabit Ethernet (2.5G/1G/100M).
Snapshots and transcoding
The supplied description states Btrfs/iSCSI snapshots and 4K video transcoding.
Who is the ASUSTOR AS3302T-V2 best for?
A strong choice for
- Home and family file storage
- Personal-cloud use
- Two-drive NAS deployments
- Users who can use a single 2.5GbE network port
- Buyers who do not require memory expansion
Consider another model if you need
- Upgradeable system memory
- More than two internal drive bays without expansion
- Built-in M.2 NVMe drive slots
- Multiple built-in Ethernet ports
Key specifications
- Model
- AS3302T-V2
- CPU
- Realtek RTD1619B
- CPU frequency
- Quad-Core 1.7GHz
- Memory
- 2GB DDR4
- Memory expandable up to
- not expandable
- Flash memory
- 8GB eMMC
- Drive bays
- 2
- Compatible drive type
- 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD
- Networking
- 1x 2.5 Gigabit Ethernet (2.5G/1G/100M)
- External expansion
- 3x USB 3.2 Gen 1
- Multimedia output
- N/A
- Power supply
- 65W x1
- Power consumption
- 13.1W (Operation) 4.5W (Disk Hibernation);
- Noise level
- 18.6dB (HDD idle)
- Operating temperature
- 0°C~40°C (32°F~104°F)
- Storage temperature
- -20°C~70°C (-4°F~158°F)
- Humidity
- 5% to 95% RH
- Warranty
- 3 Years
- Size
- 170(H) x 114(W) x 230(D) mm
- Weight
- 1.6kg / 3.53 lbs
Full technical specifications
CPU
| CPU Model | Realtek RTD1619B |
|---|---|
| CPU Architecture | ARM64 64-bit |
| CPU Frequency | Quad-Core 1.7GHz |
Memory
| Memory | 2GB DDR4 |
|---|---|
| Memory Expandable up to | not expandable |
| Flash Memory | 8GB eMMC |
Storage
| Drive Bays | 2 |
|---|---|
| Compatible Drive Type | 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD |
| Maximum Drive Bays with | 14 |
| Supports Hot Swappable Drives |
External Ports
| Expansion | 3x USB 3.2 Gen 1 |
|---|---|
| Network | 1x 2.5 Gigabit Ethernet (2.5G/1G/100M) |
| Multimedia Output | N/A |
Others
| System Fan | 1x 70mm |
|---|---|
| Power Supply Unit / Adapter | 65W x1 |
| Input Power Voltage | 100V to 240V AC |
| Certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC |
| Warranty | 3 Years |
Operation
| Power Consumption | 13.1W (Operation) 4.5W (Disk Hibernation); |
|---|---|
| Noise Level | 18.6dB (HDD idle) |
| Operation Temperature | 0°C~40°C (32°F~104°F) |
| Storage Temperature | -20°C~70°C (-4°F~158°F) |
| Humidity | 5% to 95% RH |
Size and Weight
| Size | 170(H) x 114(W) x 230(D) mm |
|---|---|
| Weight | 1.6kg / 3.53 lbs |
Frequently asked questions about the ASUSTOR AS3302T-V2
What is the ASUSTOR AS3302T-V2?
It is a 2-bay ASUSTOR Drivestor NAS with the hardware and features listed in the supplied product content.
What processor does the AS3302T-V2 use?
The exact table lists Realtek RTD1619B with Quad-Core 1.7GHz.
How much memory does the AS3302T-V2 include?
The supplied specification lists 2GB DDR4.
Can memory be upgraded on the AS3302T-V2?
The supplied table states: not expandable.
How many drive bays does the AS3302T-V2 have?
The exact specification lists 2 drive bays.
What drive types are listed for the AS3302T-V2?
The supplied compatible-drive field lists 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD.
What networking is built into the AS3302T-V2?
The exact hardware table lists 1x 2.5 Gigabit Ethernet (2.5G/1G/100M).
What warranty is listed for the AS3302T-V2?
The supplied table lists 3 Years.
- Technical specifications above come only from the supplied product content.
- The product title states “with hot-swappable tray”, while the supplied technical table does not clearly verify hot-swap support. The updated buyer-facing specifications therefore do not claim hot-swap support.
