8-bay high-performance desktop NAS
Synology DS1823xs+ 8-bay High-performance Desktop NAS
An eight-bay business NAS with AMD Ryzen processing, 8 GB ECC memory, built-in 10GbE, out-of-band management and expansion to 18 drives.
- Processor
- AMD Ryzen V1780B
- Memory
- 8 GB DDR4 ECC SODIMM
- Drive bays
- 8; up to 18 (DX517 × 2)
- Networking
- 1 × 10GbE + 2 × 1GbE + 1 × OOB
Bring data-centre capabilities to a desktop footprint
The Synology DS1823xs+ is designed for businesses that need fast shared storage, backup, VM storage or surveillance without a dedicated rack. Built-in 10GbE, out-of-band management, two M.2 NVMe slots and PCIe expansion provide multiple paths for performance and service growth.
Eight-bay business storage
Build a substantial protected storage pool in a desktop-sized enclosure.
Built-in 10GbE
A dedicated 10GbE port supports high-bandwidth workflows without using the PCIe slot.
Out-of-band management
A dedicated management port supports remote administration and recovery workflows.
Expand to 18 drives
Two DX517 units can increase the verified total drive count to eighteen.
NVMe and PCIe flexibility
Two M.2 slots and a Gen3 x8 slot support compatible cache, storage and connectivity options.
Five-year warranty
Synology specifies five years of hardware warranty coverage for this xs+ platform.
Who is the Synology DS1823xs+ best for?
A strong choice for
- Business file and application storage
- Fast backup repositories
- VM and container storage
- Media production teams
- Surveillance management without a rack
Consider another model if you need
- You need redundant power supplies
- You require more than 18 drives
- You want a lower-cost home NAS
- Your deployment does not need 10GbE or out-of-band management
Key specifications
- Model
- DS1823xs+
- Product type
- 8-bay high-performance desktop NAS
- Processor
- AMD Ryzen V1780B
- CPU cores
- 4
- CPU frequency
- 3.35 (base) / 3.6 (turbo) GHz
- System memory
- 8 GB DDR4 ECC SODIMM
- Maximum memory
- 32 GB (16 GB × 2)
- Drive bays
- 8; up to 18 (DX517 × 2)
- Drive categories
- | 3.5" SATA HDD; 2.5" SATA SSD; M.2 2280 NVMe SSD
- Built-in network
- 1 × 10GbE + 2 × 1GbE + 1 × OOB
- USB ports
- 3 × USB 3.2 Gen 1
- M.2 slots
- 2 (NVMe)
- PCIe expansion
- 1 × Gen3 ×8 slot (x4 link)
- Dimensions
- Not specified
- Weight
- 6.2 kg
- Warranty
- 5 Years
Full technical specifications
Processor, memory and storage
| CPU Model | AMD Ryzen V1780B |
|---|---|
| CPU Quantity | 1 |
| CPU Core | 4 |
| CPU Threads | 8 |
| CPU Architecture | 64-bit |
| CPU Frequency | 3.35 (base) / 3.6 (turbo) GHz |
| Hardware Encryption Engine | Supported |
| System Memory | 8 GB DDR4 ECC SODIMM |
| Memory Module Pre-installed | 8 GB (8 GB × 1) |
| Total Memory Slots | 2 |
| Maximum Memory Capacity | 32 GB (16 GB × 2) |
| Memory notes | | Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.; Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.; For more information about the recommended memory configurations, please check the of your Synology product. |
| Drive Bays | 8 |
| Maximum Drive Bays with Expansion Unit | 18 (DX517 × 2) |
| M.2 Drive Slots | 2 (NVMe) |
| Drive Type | | 3.5" SATA HDD; 2.5" SATA SSD; M.2 2280 NVMe SSD |
| Hot Swappable Drive* | Supported |
| Storage notes | | The hot swappable drive feature is not supported by M.2 SSD slots.; Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the. The use of non-validated components may limit certain functionality and result in data loss and system instability. |
Network, ports and expansion
| RJ-45 1GbE LAN Port | 2 |
|---|---|
| RJ-45 10GbE LAN Port | 1 |
| Out-of-Band Management LAN Port | 1 |
| USB 3.2 Gen 1 Port* | 3 |
| Expansion Port | 2 |
| Expansion Port Type | eSATA |
| External Ports notes | This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes. |
| PCIe Expansion | 1 × Gen3 ×8 slot (x4 link) |
| Optional Accessories | | DDR4 ECC SODIMM: D4ES02-8G/D4ES01-16G; Expansion Units: DX517; Enterprise Series 3.5" SATA HDD: HAT5300 Series; Plus Series 3.5" SATA HDD: HAT3300 Series; Enterprise Series 2.5" SATA SSD: SAT5200 Series; Enterprise Series M.2 2280 NVMe SSD: SNV3400 Series; 25GbE Network Interface Card: E25G30-F2; 10GbE Network Interface Card: E10G30-F2/E10G30-T2/E10G18-T1 |
Physical design and power
| Size (Height × Width × Depth) | 166 mm × 343 mm × 243 mm |
|---|---|
| Weight | 6.2 kg |
| System Fan | 120 mm × 120 mm × 2 pcs |
| Fan Speed Mode | | Full-Speed Mode; Cool Mode; Quiet Mode |
| Easy Replacement System Fan | Supported |
| Brightness Adjustable Front LED Indicators | Supported |
| Power Recovery | Supported |
| Noise Level* | 23.6 dB(A) |
| Scheduled Power On / Off | Supported |
| Wake on LAN / WAN | Supported |
| Power Supply Unit / Adapter | 250 watts |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 87.93 watts (Access); 28.37 watts (HDD Hibernation) |
| British Thermal Unit | 300.23 BTU/hr (Access); 96.87 BTU/hr (HDD Hibernation) |
| Others notes | | For more information on how power consumption is measured, refer to; Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75°C; Humidity: 58.2-61.8% |
Environment, warranty and package
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
|---|---|
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Operating Humidity | 8% to 80% RH |
| Storage Humidity | 5% to 95% RH |
| Certification | | FCC; CE; BSMI; VCCI; RCM; EAC; CCC; KC; BIS |
| Warranty | 5 Years |
| Warranty notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
| Environment | RoHS Compliant |
| Packaging Content | | Main Unit X 1; Accessory Pack X 1; AC Power Cord X 1; RJ-45 LAN Cable X 2; Quick Installation Guide X 1 |
Frequently asked questions about the Synology DS1823xs+
What is the Synology DS1823xs+?
The Synology DS1823xs+ is a 8-bay high-performance desktop NAS for business file and application storage, fast backup repositories, vm and container storage.
Which processor is in the Synology DS1823xs+?
It uses the AMD Ryzen V1780B with 4 cores at 3.35 (base) / 3.6 (turbo) GHz.
How much memory does the Synology DS1823xs+ include?
It includes 8 GB DDR4 ECC SODIMM and the supplied maximum memory capacity is 32 GB (16 GB × 2).
How many drive bays does the Synology DS1823xs+ have?
It has 8 internal drive bays and supports the supplied maximum of 18 (DX517 × 2).
Which drive types does the Synology DS1823xs+ support?
| 3.5" SATA HDD; 2.5" SATA SSD; M.2 2280 NVMe SSD. Confirm exact drive models on Synology’s compatibility list.
What networking is built into the Synology DS1823xs+?
The verified built-in network interfaces are 1 × 10GbE + 2 × 1GbE + 1 × OOB.
Can the Synology DS1823xs+ expand beyond its internal bays?
Yes. The verified maximum is 18 (DX517 × 2). Expansion units are sold separately.
Does the Synology DS1823xs+ include storage drives?
No. This listing identifies the Synology DS1823xs+ as diskless, so compatible drives are selected separately.
What are the Synology DS1823xs+ dimensions?
It measures Not specified and weighs 6.2 kg.
What warranty applies to the Synology DS1823xs+?
Synology specifies 5 years. Warranty-extension availability depends on region.
- DS1823xs+ is listed as diskless; compatible storage drives are selected separately.
- Confirm exact drives, memory and accessories on Synology’s compatibility list for DS1823xs+.
- Expansion units required to reach 18 (DX517 × 2) are sold separately.
- M.2 SSD bays are not hot-swappable; confirm the supported SSD role and exact models before purchase.
- Actual usable capacity and performance depend on installed drives, storage configuration, workloads and network environment.
