Economical, high-performance data management solution for SMBs
Combine all-flash performance with Synology systems’ ease of use and reliability. The FS3410 is designed to tackle scenarios that require high throughput and low latency.
Storage
Supports 24 x 2.5” SATA SSDs
Memory
16 GB DDR4 ECC RDIMM, up to 128 GB
Expandability
Optional 25/40GbE through PCIe 3.0 expansion
Specification
|
Hardware Specifications
|
||
|---|---|---|
|
CPU
|
CPU Model | Intel Xeon D-1541 |
| CPU Quantity | 1 | |
| CPU Core | 8 | |
| CPU Architecture | 64-bit | |
| CPU Frequency | 2.1 (base) / 2.7 (turbo) GHz | |
| Hardware Encryption Engine |
|
|
|
Memory
|
System Memory | 16 GB DDR4 ECC RDIMM |
| Memory Module Pre-installed | 16 GB (16 GB x 1) | |
| Total Memory Slots | 4 | |
| Maximum Memory Capacity | 128 GB (32 GB x 4) | |
| Notes |
|
|
|
Storage
|
Drive Bays | 24 |
| Drive Type | 2.5" SATA SSD | |
| Hot Swappable Drive* |
|
|
| Notes | The use of non-validated components may limit certain functionality and result in data loss and system instability. | |
|
External Ports
|
RJ-45 1GbE LAN Port | 4 |
| RJ-45 10GbE LAN Port | 2 | |
| Out-of-Band Management LAN Port | 1 | |
| Max. Number of LAN Ports | 15 | |
| USB 3.2 Gen 1 Port* | 2 | |
| Notes |
|
|
|
PCIe
|
PCIe Expansion | 2 x Gen3 x8 slots (x8 link) |
|
Appearance
|
Form Factor (RU) | 2U |
| Size (Height x Width x Depth) | 88 mm x 482 mm x 724 mm | |
| Weight | 15.0 kg | |
| Rack Installation Support* | 4-post 19" rack | |
| Notes | The rail kit is sold separately | |
|
Others
|
System Fan | 80 mm x 80 mm x 4 pcs |
| Fan Speed Mode |
|
|
| Easy Replacement System Fan |
|
|
| Power Recovery |
|
|
| Noise Level* | 46.1 dB(A) | |
| Scheduled Power On / Off |
|
|
| Wake on LAN / WAN |
|
|
| Power Supply Unit / Adapter | 550 watts | |
| Redundant Power Supply |
|
|
| AC Input Power Voltage | 100V to 240V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption | 113.84 watts (Access) |
|
| British Thermal Unit | 388.70 BTU/hr (Access) |
|
| Notes |
|
|
|
Temperature
|
Operating Temperature | 0°C to 35°C (32°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
|
Certification
|
|
|
|
Warranty
|
5 Years | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. | |
|
Environment
|
RoHS Compliant | |
|
Packaging Content
|
|
|
