Synology SA3200D ,12-Bay Intel Xeon D-1521 ,8GB DDR4 ,Dual Controller 3.5" Diskless NAS ,1 x Gen3 x8 slot (x8 link) (per controller)
Regular price
$12,284.00
Sold Out
Adding product to your cart
Maximizing availability has never been this easy
Simplify and centralize your data management infrastructure with Synology SA3200D. Storage controller redundancy powered by Synology High Availability automatically minimizes downtime to under a minute, delivering outstanding cost effectiveness in just a 2U footprint.
High Availability
Dual storage controllers
Cost-effective
Shared storage design
Effortless
Automatic system-level protection
Scalable
Up to 36 drives for 576 TB
Specification
|
Hardware Specifications
|
|
Controller
|
Number of Controller Module |
2 |
|
CPU
|
CPU Model |
Intel Xeon D-1521 |
|
CPU Quantity |
1 (per controller) |
|
CPU Core |
4 |
|
CPU Architecture |
64-bit |
|
CPU Frequency |
2.4 (base) / 2.7 (turbo) GHz |
|
Hardware Encryption Engine |
|
|
Memory
|
System Memory |
8 GB DDR4 ECC UDIMM (per controller) |
|
Memory Module Pre-installed |
8 GB (8 GB x 1) (per controller) |
|
Total Memory Slots |
4 (per controller) |
|
Maximum Memory Capacity |
64 GB (16 GB x 4) (per controller) |
|
Notes |
- Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
- Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
- For more information on the recommended memory configurations.
|
|
Storage
|
Drive Bays |
12 |
|
Maximum Drive Bays with Expansion Unit |
36 (RXD1219sas x 2) |
|
Drive Type
|
- 3.5” dual port SAS HDD
- 2.5” dual port SAS HDD
- 2.5” dual port SAS SSD
|
|
Hot Swappable Drive* |
|
|
External Ports
|
RJ-45 1GbE LAN Port |
2 (per controller) |
|
RJ-45 10GbE LAN Port |
1 (per controller) |
|
Expansion Port |
1 (per controller) |
|
Expansion Port Type |
Mini-SAS HD |
|
PCIe
|
PCIe Expansion |
1 x Gen3 x8 slot (x8 link) (per controller) |
|
Appearance
|
Form Factor (RU) |
2U |
|
Size (Height x Width x Depth) |
88 mm x 482 mm x 724 mm |
|
Weight |
19.7 kg |
|
Rack Installation Support* |
4-post 19" rack |
|
Notes |
The rail kit is sold separately |
|
Others
|
System Fan |
60 mm x 60 mm x 2 pcs |
|
Fan Speed Mode |
- Full-Speed Mode
- Cool Mode
- Quiet Mode
|
|
Easy Replacement System Fan |
|
|
Power Recovery |
|
|
Noise Level* |
51.3 dB(A) |
|
Power Supply Unit / Adapter |
500 watts |
|
Redundant Power Supply |
|
|
AC Input Power Voltage |
100V to 240V AC |
|
Power Frequency |
50/60 Hz, Single Phase |
|
Power Consumption |
417.48 watts (Access)
|
|
British Thermal Unit |
1425.45 BTU/hr (Access)
|
|
Notes |
- Power consumption is measured when it is fully loaded with Seagate ST3600057SS hard drive(s).
- Noise Level Testing Environment: Fully loaded with Seagate ST8000NM0075 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology server at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%.
|
|
Temperature
|
Operating Temperature |
0°C to 35°C (32°F to 95°F) |
|
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
|
Relative Humidity |
5% to 95% RH |
|
Certification
|
- FCC
- CE
- BSMI
- VCCI
- RCM
- EAC
- CCC
- BIS
|
|
Warranty
|
5 Years |
|
Notes |
The warranty period starts from the purchase date as stated on your purchase receipt.
|
|
Environment
|
RoHS Compliant |
|
Packaging Content
|
- Main Unit X 1
- Accessory Pack X 1
- AC Power Cord X 2
- Quick Installation Guide X 1
|
