Fast and reliable

Over 6,200/3,000 MB/s seq. read/write,² built-in 10GbE, and hardware and software redundancy.

Expand and adjust

Add up to 84 extra drive bays, 40GbE or Fibre Channel, and SSD cache volumes whenever needed.

Host core applications

Back up 1,000+ endpoints, manage 128 IP cameras, or provide mailboxes for up to 1,600 users.

Specification

Hardware Specifications		SA3610
CPU	CPU Model	Intel Xeon D-1567
	CPU Quantity	1
	CPU Core	12
	CPU Architecture	64-bit
	CPU Frequency	2.1 (base) / 2.7 (turbo) GHz
	Hardware Encryption Engine
Memory	System Memory	16 GB DDR4 ECC RDIMM
	Memory Module Pre-installed	16 GB (16 GB x 1)
	Total Memory Slots	4
	Maximum Memory Capacity	128 GB (32 GB x 4)
	Notes	Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion. Installing memory modules with differing capacities is not recommended. Check of your Synology product for recommended memory configurations.
Storage	Drive Bays	12
	Maximum Drive Bays with Expansion Unit	96 (RX1222sas x 7)
	Drive Type	3.5" SAS HDD 2.5" SAS SSD 3.5" SATA HDD 2.5" SATA SSD
	Hot Swappable Drive*
	Notes	Synology only guarantees full functionality, reliability, and performance for Synology drives listed on . The use of non-validated components may limit certain functionality and result in data loss and system instability.
External Ports	RJ-45 1GbE LAN Port	4
	RJ-45 10GbE LAN Port	2
	Out-of-Band Management LAN Port	1
	Max. Number of LAN Ports	15
	USB 3.2 Gen 1 Port*	2
	Expansion Port	1
	Expansion Port Type	Mini-SAS HD
	Notes	This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes. The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
PCIe	PCIe Expansion	2 x Gen3 x8 slots (x8 link)
Appearance	Form Factor (RU)	2U
	Size (Height x Width x Depth)	88 mm x 482 mm x 724 mm
	Weight	14.5 kg
	Rack Installation Support*	4-post 19" rack
	Notes	The rail kit is sold separately
Others	System Fan	80 mm x 80 mm x 4 pcs
	Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
	Easy Replacement System Fan
	Power Recovery
	Noise Level*	49.8 dB(A)
	Scheduled Power On / Off
	Wake on LAN / WAN
	Power Supply Unit / Adapter	550 watts
	Redundant Power Supply
	AC Input Power Voltage	100V to 240V AC
	Power Frequency	50/60 Hz, Single Phase
	Power Consumption	137.54 watts (Access) 58.23 watts (HDD Hibernation)
	British Thermal Unit	469.30 BTU/hr (Access) 198.68 BTU/hr (HDD Hibernation)
	Notes	Noise testing was conducted with the Synology system fully installed with Synology SATA SSDs and in an idle state. Two G.R.A.S. type 40AE microphones were placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%.
Temperature	Operating Temperature	0°C to 35°C (32°F to 95°F)
	Storage Temperature	-20°C to 60°C (-5°F to 140°F)
	Relative Humidity	5% to 95% RH
Certification		FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL
Warranty		5 Years
	Notes	The warranty period starts from the purchase date as stated on your purchase receipt.
Environment		RoHS Compliant
Packaging Content		Main Unit X 1 Accessory Pack X 1 AC Power Cord X 2 Quick Installation Guide X 1
