4-bay 1U business NAS with redundant power
Synology RackStation RS826RP+ 4-Bay NAS
The Synology RackStation RS826RP+ is a four-bay, 1U rackmount network attached storage system with an AMD Ryzen V1500B processor, 4 GB of ECC memory, four 1GbE ports and expansion options for growing business storage.
- Processor
- AMD Ryzen V1500B, 4-core, 2.2 GHz
- Memory
- 4 GB DDR4 ECC; up to 32 GB
- Drive bays
- 4; up to 8 with RX426
- Networking
- 4 x 1GbE RJ-45
Flexible rackmount storage for business data
The RS826RP+ provides centralised file storage, backup and cross-site sharing in a compact 1U chassis. Its four built-in 1GbE ports, PCIe slot and RX426 expansion support allow organisations to adapt networking and capacity as requirements grow, while the redundant power configuration adds resilience for supported rack deployments.
Consistent business platform
A quad-core AMD Ryzen processor and ECC memory support dependable day-to-day storage and data-management services.
Four-bay SATA storage
Use supported 3.5-inch SATA HDDs or 2.5-inch SATA SSDs in four hot-swappable bays.
Capacity expansion
A separately sold RX426 expansion unit increases the supported bay count from four to eight.
Network upgrade path
The supplied PCIe slot supports listed 10GbE or 25GbE network-interface options for compatible deployments.
Backup and collaboration
The supplied positioning covers endpoint backup, file synchronisation and controlled sharing across sites.
Redundant power
Dual included AC power cords and redundant power support help reduce a single power-supply point of failure.
Who is the Synology RS826RP+ best for?
A strong choice for
- Small and medium business shared storage
- Rack-based backup and file-sync workflows
- Sites that need four built-in 1GbE ports
- Teams planning later 10GbE or 25GbE expansion
- Video-management deployments requiring up to 40 listed IP cameras
- Racks where redundant power is required
Consider another model if you need
- You need more than eight supported drive bays
- You require built-in 10GbE or 25GbE rather than an optional adapter
- A single-power-supply model better matches your budget and resilience requirements
Key specifications
- Processor
- AMD Ryzen V1500B, 4-core, 2.2 GHz
- Memory
- 4 GB DDR4 ECC SODIMM; maximum 32 GB
- Drive bays
- 4; maximum 8 with 1 x RX426
- Drive types
- 3.5-inch SATA HDD and 2.5-inch SATA SSD
- Networking
- 4 x 1GbE RJ-45
- Expansion
- 1 x USB Type-C expansion port; 1 x PCIe Gen3 x8 slot with x4 link
- Dimensions
- 44 x 480 x 492.6 mm
- Weight
- 6.4 kg
- Power
- Redundant 150 W power supply configuration
- Warranty
- 3 years; extendable to 5 years with EW202 where available
Full technical specifications
Processor and memory
| CPU model | AMD Ryzen V1500B |
|---|---|
| CPU quantity | 1 |
| CPU cores | 4 |
| CPU architecture | 64-bit |
| CPU frequency | 2.2 GHz |
| Hardware encryption engine | Supported |
| System memory | 4 GB DDR4 ECC SODIMM |
| Pre-installed memory | 4 GB (4 GB x 1) |
| Total memory slots | 2 |
| Maximum memory capacity | 32 GB (16 GB x 2) |
| Memory notes | Synology may revise pre-installed memory module specifications following validation. Synology memory modules are recommended, and multi-module configurations must use identical modules with the same model number. |
Storage, ports and expansion
| Drive bays | 4 |
|---|---|
| Maximum drive bays with expansion | 8 using 1 x RX426 |
| Drive types | 3.5-inch SATA HDD; 2.5-inch SATA SSD |
| Hot-swappable drives | Supported |
| RJ-45 1GbE LAN ports | 4 |
| USB 3.2 Gen 1 ports | 2 |
| Expansion port | 1 |
| Expansion port type | USB Type-C |
| PCIe expansion | 1 x Gen3 x8 slot with x4 link |
Physical, power and environmental
| Form factor | 1U |
|---|---|
| Dimensions | 44 x 480 x 492.6 mm (H x W x D) |
| Weight | 6.4 kg |
| Rack installation support | 4-post 19-inch rack |
| Rail kit | Sold separately |
| System fans | 3 x 40 mm x 40 mm |
| Fan speed modes | Full-Speed Mode, Cool Mode and Quiet Mode |
| Power recovery | Supported |
| Noise level | 27.4 dB(A) |
| Scheduled power on/off | Supported |
| Wake on LAN/WAN | Supported |
| Power supply | 150 W |
| Redundant power supply | Yes |
| AC input voltage | 100 V to 240 V AC |
| Power frequency | 50/60 Hz, single phase |
| Power consumption | 47.69 W access; 16.7 W HDD hibernation |
| British thermal unit | 162.83 BTU/hr access; 57.02 BTU/hr HDD hibernation |
| Operating temperature | 0°C to 35°C (32°F to 95°F) |
| Storage temperature | -20°C to 60°C (-5°F to 140°F) |
| Operating humidity | 8% to 80% RH |
Certification, warranty and package
| Certifications | FCC, CE, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC, BIS and UL |
|---|---|
| Warranty | 3-year hardware warranty, extendable to 5 years with EW202 |
| Environmental compliance | RoHS compliant |
| Package contents | 1 x main unit; 1 x accessory pack; 2 x AC power cords |
| Memory accessories | D4ES04-4G, D4ES03-8G and D4ES03-16G |
| Expansion unit | RX426 |
| Supported drive-series accessories | HAT5300 Series, HAT3300 Series and SAT5200 Series |
| Network and M.2 adapter options | E10M20-T1, M2D20, E25G30-F2, E10G30-F2, E10G30-T2 and E10G30-T1 |
| Rail-kit options | RKS-02 and RKM114 |
Frequently asked questions about the Synology RS826RP+
What is the Synology RS826RP+?
The RS826RP+ is a four-bay, 1U rackmount NAS for centralised business storage, backup, synchronisation and video-management workloads described in the supplied product information.
What processor does the RS826RP+ use?
It uses one quad-core AMD Ryzen V1500B processor running at 2.2 GHz.
How much memory is included with the RS826RP+?
The RS826RP+ includes 4 GB of DDR4 ECC SODIMM memory and supports up to 32 GB using two 16 GB modules.
How many drives can the RS826RP+ support?
It has four internal bays and supports up to eight bays with one separately sold RX426 expansion unit.
Which drive types fit the RS826RP+?
The supplied specifications list 3.5-inch SATA HDDs and 2.5-inch SATA SSDs; confirm the exact drive on Synology's compatibility list before purchase.
What network ports are built into the RS826RP+?
It includes four RJ-45 1GbE LAN ports.
Can the RS826RP+ be upgraded to faster networking?
The supplied options list compatible 10GbE and 25GbE interface cards for its PCIe expansion slot.
Does the RS826RP+ support hot-swappable drives?
Yes. Hot-swappable drive support is listed in the supplied specifications.
Does the RS826RP+ have redundant power?
Yes. The RS826RP+ is the redundant-power version and includes two AC power cords.
What warranty applies to the RS826RP+?
The supplied specification states a three-year hardware warranty, extendable to five years with EW202 where that service is available.
- This is a diskless NAS; drives are sold separately.
- The RX426 expansion unit, network cards, memory upgrades and rail kits are optional accessories.
- The supplied warranty note states that EW201/EW202 availability is limited by country or region.
- Confirm all drives, memory and expansion accessories against Synology's current compatibility information before purchase.
