30-bay Ryzen 7 all-flash rackmount NAS
QNAP TS-h3077AFU-R7-64G
A 2U all-flash rackmount NAS supplied with an AMD Ryzen 7 7000 series 8-core processor, 64GB DDR5, thirty 2.5-inch SATA SSD bays, dual 10GBASE-T and dual 2.5GbE connectivity.
Thirty-bay SATA all-flash storage with DDR5 and expansion
The QNAP TS-h3077AFU-R7-64G is a 30-bay SATA SSD all-flash NAS powered by an eight-core AMD Ryzen 7 7000 series processor and 64GB DDR5. The supplied content positions it for media production, enterprise data, scientific research, virtual machines and high-volume business assets, with QuTS hero SSD-management features and PCIe networking expansion.
Key features and benefits
Thirty-bay all-flash design
Thirty 2.5-inch SATA bays provide a dense SSD storage platform in a 2U rackmount chassis.
Ryzen 7 with DDR5
The eight-core Ryzen 7 platform is paired with 64GB DDR5 and a listed maximum of 192GB.
Built-in multi-gigabit networking
Two 10GBASE-T ports and two 2.5GbE ports are supplied.
Three PCIe Gen 4 slots
The source lists three expansion slots and describes optional 25GbE or 100GbE network adapters.
Integrated Radeon graphics
AMD Radeon Graphics and hardware-accelerated transcoding are listed in the technical table.
SSD-focused QuTS hero features
The source includes inline deduplication, QSAL and other SSD performance and lifespan features.
Who is the QNAP TS-h3077AFU-R7-64G best for?
A strong choice for
- Media-production storage
- Enterprise and research datasets
- Virtual machines and intensive file access
- Large backup and restoration tasks
- Thirty-drive SATA SSD deployments
Consider another model if you need
- Support beyond the supplied availability statement of up to 2030
- U.2 or NVMe drive bays rather than 2.5-inch SATA
- A tower enclosure
- More than 192GB maximum memory
- A configuration supplied with SSDs where none are stated
Key specifications
- Processor
- AMD Ryzen 7 7000 series, 8-core/16-thread, burst up to 5.3GHz; AMD Radeon Graphics
- Memory
- 64GB UDIMM DDR5 (2 × 32GB); maximum 192GB (4 × 48GB); optional ECC memory supported
- Drive bays
- 30 × 2.5-inch SATA 6Gb/s, 3Gb/s
- Drive compatibility
- 2.5-inch SATA solid-state drives
- Networking
- 2 × 10GBASE-T; 2 × 2.5GbE
- PCIe
- 3 slots: Gen 4 x4; Gen 4 x8 or x4; Gen 4 x4
- USB
- 2 × Type-A USB 3.2 Gen 2, 10Gbps
- Form factor
- 2U rackmount
- Dimensions
- 88.3 × 482 × 549.7 mm, excluding ear hook and protruding PSU section
- Net weight
- 12.73 kg
- Power supply
- 2 × 550W, 100–240V
- Standard warranty
- 5 (unit not stated in supplied source)
Full technical specifications
View all supplied technical specifications
| CPU | AMD Ryzen™ 7 7000 series 8-core/16-thread processor, burst up to 5.3 GHz AMD Radeon Graphics |
|---|---|
| CPU Architecture | 64-bit x86 |
| Graphic Processors | AMD Radeon™ Graphics |
| Floating Point Unit | Supported |
| Encryption Engine | Supported (AES-NI) |
| Hardware-accelerated Transcoding | Supported |
| System Memory | 64 GB UDIMM DDR5 (2x 32 GB) |
| Maximum Memory | 192 GB (4 x 48 GB) |
| Memory Slot | 4 x UDIMM DDR5 Support optional ECC memory |
| Flash Memory | 5GB (Dual boot OS protection) |
| Drive Bay | 30 x 2.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 2.5-inch SATA solid state drives |
| Hot-swappable | Supported |
| SSD Cache Acceleration Support | Supported |
| GPU pass-through | Supported |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
| 10 Gigabit Ethernet Port | 2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| Wake on LAN (WOL) | Supported |
| Jumbo Frame | Supported |
| PCIe Slot | 3 Slot 1: Gen 4 x 4 Slot 2: Gen 4 x 8 or Gen 4 x 4* Slot 3: Gen 4 x 4 *Slot 2 provides the width of PCIe Gen4 x8 when Slot 1 is not in use, and provides the width of PCIe Gen4 x4 when Slot 1 is in use. |
| USB 3.2 Gen 2 (10Gbps) Port | 2 x Type-A USB 3.2 Gen 2 10Gbps |
| Form Factor | 2U Rackmount |
| LED Indicators | Power Status, SSD 1-30, Status, LAN, storage expansion port status |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 88.3 × 482 × 549.7 mm Excludes ear hook and the protruding part of the Power Supply Unit. |
| Weight (Net) | 12.73 kg |
| Weight (Gross) | 18.69 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit | 550W(x2), 100-240V |
| Power Consumption: Operating Mode, Typical | 380.23 W Tested with drives fully populated. |
| Fan | System fan: 3 x 60mm, 12VDC |
| System Warning | Buzzer |
| Standard Warranty | 5 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 5000 |
Frequently asked questions about the QNAP TS-h3077AFU-R7-64G
What is the QNAP TS-h3077AFU-R7-64G?
It is a 30-bay 2U SATA SSD all-flash NAS with an eight-core Ryzen 7 7000 series processor, 64GB DDR5 and built-in 10GbE and 2.5GbE.
What drives does it support?
The supplied table lists 2.5-inch SATA solid-state drives across thirty bays.
How much memory is installed?
The table lists 64GB DDR5 as two 32GB modules and a maximum of 192GB.
What networking is built in?
Two 10GBASE-T ports and two 2.5GbE ports are listed.
Does it have PCIe expansion?
Yes. Three PCIe Gen 4 slots are listed, with slot width depending partly on whether adjacent slots are used.
What long-term availability is supplied?
The source states availability and support up to 2030. Current status should be confirmed before purchase.
What is the warranty period?
The source provides the value 5 without a unit, so the duration cannot be confirmed.
