6-bay business and media NAS
QNAP TVS-675-8G
A 6-bay NAS supplied with a Zhaoxin KaiXian KX-U6580 8-core processor, 8GB DDR4 memory, dual 2.5GbE, two M.2 slots and two PCIe expansion slots.
Flexible 2.5GbE storage for everyday business workloads
The QNAP TVS-675-8G combines six SATA drive bays with an 8-core Zhaoxin processor and 8GB DDR4 memory. Based on the supplied description, it is designed for file backup and restore, team collaboration, snapshots, virtual machines, containers, media playback and expandable storage, with M.2 and PCIe options for future configuration needs.
Key features and benefits
Eight-core x86 processing
The supplied Zhaoxin KaiXian KX-U6580 processor provides eight cores at 2.5GHz.
Dual 2.5GbE connectivity
Two built-in 2.5GbE ports are listed, with port trunking described for transfer speeds up to 5Gbps.
Flexible M.2 storage
Two M.2 2280 slots accept the supplied PCIe Gen 3 x1 NVMe or SATA 6Gb/s configurations.
PCIe expansion
Two PCIe Gen 3 x4 slots are listed for supported networking, QM2 or QXP expansion cards.
HDMI media output
HDMI 2.0 output up to 3840 × 2160 at 60Hz and real-time transcoding are supplied.
Expandable storage capacity
The supplied overview states that QNAP expansion enclosures can be connected as storage needs grow.
Who is the QNAP TVS-675-8G best for?
A strong choice for
- Business file backup and restore
- Shared storage for team collaboration
- Snapshot-based data protection
- Virtual machines and containers
- Media playback and real-time transcoding
- Buyers planning M.2 or PCIe expansion
Consider another model if you need
- Built-in 5GbE or 10GbE networking
- More than 6 internal drive bays
- A rackmount enclosure
- Memory requirements above 64GB
- A processor platform other than the supplied Zhaoxin model
Key specifications
- Processor
- Zhaoxin KX-U6580 8-core 2.5GHz processor
- Graphics
- Zhaoxin C-960 Graphics
- Memory
- 8GB SODIMM DDR4 (1 × 8GB); maximum 64GB (2 × 32GB)
- Drive bays
- 6 × 3.5-inch SATA 6Gb/s, 3Gb/s
- Drive compatibility
- 3.5-inch SATA hard drives; 2.5-inch SATA solid-state drives
- M.2 slots
- 2 × M.2 2280 PCIe Gen 3 x1 or SATA 6Gb/s; compatible with NVMe SSD PCIe Gen 3 and above
- Networking
- 2 × 2.5GbE; 5GbE and 10GbE optional via adapter
- PCIe
- 2 × PCIe Gen 3 x4 slots
- USB
- 2 × USB 3.2 Gen 1; 2 × USB-A 3.2 Gen 2
- HDMI
- 1 × HDMI 2.0, up to 3840 × 2160 at 60Hz
- Dimensions
- 180.2 × 264.3 × 279.6 mm
- Net weight
- 7 kg
- Standard warranty
- 3 (unit not stated in supplied source)
Full technical specifications
View all supplied technical specifications
| CPU | ZhaoXin KX-U6580 8-core 2.5GHz processor |
|---|---|
| CPU Architecture | 64-bit x86 |
| Graphic Processors | ZhaoXin C-960 Graphics |
| Floating Point Unit | Supported |
| Encryption Engine | Supported (AES-NI) |
| Hardware-accelerated Transcoding | Supported |
| System Memory | 8 GB SODIMM DDR4 (1 x 8 GB) |
| Maximum Memory | 64GB (2 x 32 GB) |
| Memory Slot | 2 x SODIMM DDR4 For dual-DIMM configuration, you must use a pair of identical DDR4 modules. |
| Flash Memory | 5GB (Dual boot OS protection) |
| Drive Bay | 6 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-swappable | Supported |
| M.2 Slot | 2 x M.2 2280 PCIe Gen 3 x1 or SATA 6Gb/s slots Compatible with NVMe SSD PCIe Gen 3 and above. |
| SSD Cache Acceleration Support | Supported |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M) |
| 5 Gigabit Ethernet Port (5G/2.5G/1G/100M) | Optional via an adapter |
| 10 Gigabit Ethernet Port | Optional via an adapter |
| Wake on LAN (WOL) | Supported Only the 2.5GbE port |
| Jumbo Frame | Supported |
| PCIe Slot | 2 Slot 1: PCIe Gen 3 x4 Slot 2: PCIe Gen 3 x4 Card dimensions for PCIe slot 1~Slot 2:190 x 111.15 x 18.76 mm / 7.48 x 4.38 x 0.74 inches. Wider cards can be installed if the next PCIe slot will not be used. |
| USB 3.2 Gen 1 port | 2 |
| USB 3.2 Gen 2 (10Gbps) Port | 2 x Type-A |
| HDMI™ Output | 1, HDMI™ 2.0 (up to 3840 x 2160 @ 60Hz) |
| Form Factor | Tower |
| LED Indicators | HDD 1-6, Status, LAN, USB, M.2 SSD 1-2 |
| Buttons | Power, Reset, USB Copy |
| Dimensions (HxWxD) | 180.2 × 264.3 × 279.6 mm Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
| Weight (Net) | 7 kg |
| Weight (Gross) | 7.8 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27°C (80.6˚F) |
| Power Supply Unit | 250W, 100-240V AC, 50/60Hz, 3.5A |
| Power Consumption: HDD Sleep Mode | 41.897 W |
| Power Consumption: Operating Mode, Typical | 60.794 W |
| Fan | 3 x 80mm, 12VDC |
| System Warning | Buzzer |
| Kensington Security Slot | Supported |
| Standard Warranty | 3 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 2000 |
Frequently asked questions about the QNAP TVS-675-8G
What is the QNAP TVS-675-8G?
It is a 6-bay tower NAS supplied with a Zhaoxin KX-U6580 8-core processor, 8GB DDR4 memory and two 2.5GbE ports.
Can its memory be expanded?
The supplied specification lists 8GB installed and a maximum of 64GB across two SODIMM slots. It also says a dual-DIMM configuration must use identical DDR4 modules.
Which drives are listed for the main bays?
The source lists 3.5-inch SATA hard drives and 2.5-inch SATA solid-state drives.
What can be installed in the M.2 slots?
The supplied specification lists M.2 2280 PCIe Gen 3 x1 NVMe SSDs or SATA 6Gb/s SSDs.
Does it include 10GbE?
No built-in 10GbE port is listed. The source says 10GbE is optional through an adapter.
What HDMI output is supplied?
One HDMI 2.0 output is listed, supporting up to 3840 × 2160 at 60Hz.
What is the warranty period?
The source provides the value 3 without a unit, so the warranty duration cannot be confirmed.
