4-bay QuTS hero NAS
QNAP TVS-h474-PT-8G
A 4-bay QuTS hero NAS supplied with an Intel Pentium Gold G7400 2-core processor, 8GB DDR4 memory, dual 2.5GbE, two M.2 PCIe Gen 3 slots and two PCIe expansion slots.
Compact QuTS hero storage with M.2 and PCIe expansion
The QNAP TVS-h474-PT-8G combines four SATA bays with ZFS-based QuTS hero, an Intel Pentium Gold G7400 processor and 8GB DDR4 memory. Based on the supplied description, it supports business file storage, backup and recovery, virtual machines and containers, with dual 2.5GbE networking and options for M.2 and PCIe expansion.
Key features and benefits
ZFS-based storage platform
The supplied overview lists inline data deduplication and compression, snapshots, real-time SnapSync and SSD optimisation.
Compact 4-bay design
Four 3.5-inch SATA bays are supplied in a tower enclosure.
Upgradeable memory
The specification lists 8GB installed and a maximum of 64GB across two DDR4 SODIMM slots.
M.2 NVMe capability
Two M.2 2280 PCIe Gen 3 x2 slots are listed for compatible NVMe SSDs.
PCIe expansion options
Two slots are supplied: one PCIe Gen 4 x16 and one PCIe Gen 3 x2.
Built-in graphics and HDMI
Intel UHD Graphics 710, hardware-accelerated transcoding and HDMI 1.4b output are listed.
Who is the QNAP TVS-h474-PT-8G best for?
A strong choice for
- Small business file storage
- Backup and recovery
- Teams needing four SATA bays
- Buyers wanting 2.5GbE connectivity
- Deployments that may use M.2 or PCIe expansion
Consider another model if you need
- More than 4 internal drive bays
- A higher-core installed processor
- Direct Thunderbolt connectivity
- A rackmount form factor
- Built-in 5GbE or 10GbE
Key specifications
- Processor
- Intel Pentium Gold G7400 2-core / 4-thread 3.7GHz processor
- Graphics
- Intel UHD Graphics 710
- Memory
- 8GB SODIMM DDR4 (1 × 8GB); maximum 64GB (2 × 32GB)
- Drive bays
- 4 × 3.5-inch SATA 6Gb/s, 3Gb/s
- Drive compatibility
- 3.5-inch SATA hard drives; 2.5-inch SATA solid-state drives
- M.2 slots
- 2 × M.2 2280 PCIe Gen 3 x2; compatible with NVMe SSD PCIe Gen 3 and above
- Networking
- 2 × 2.5GbE; 5GbE and 10GbE optional via PCIe expansion card
- PCIe
- 2 slots: PCIe Gen 4 x16 and PCIe Gen 3 x2
- USB
- 1 × USB 3.2 Gen 1; 1 × USB-C 3.2 Gen 2; 1 × USB-A 3.2 Gen 2
- HDMI
- 1 × HDMI 1.4b, up to 4096 × 2160 at 30Hz
- Dimensions
- 180.2 × 199.3 × 279.6 mm
- Net weight
- 6.1 kg
- Standard warranty
- 3 (unit not stated in supplied source)
Full technical specifications
View all supplied technical specifications
| CPU | Intel® Pentium® Gold G7400 2-core/4-thread 3.7 GHz Processor |
|---|---|
| CPU Architecture | 64-bit x86 |
| Graphic Processors | Intel® UHD Graphics 710 |
| Floating Point Unit | Supported |
| Encryption Engine | Supported (AES-NI) |
| Hardware-accelerated Transcoding | Supported |
| System Memory | 8 GB SODIMM DDR4 (1 x 8 GB) |
| Maximum Memory | 64 GB ( 2 x 32 GB) |
| Memory Slot | 2 x SODIMM DDR4 |
| Flash Memory | 5GB (Dual boot OS protection) |
| Drive Bay | 4 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-swappable | Supported |
| M.2 Slot | 2 x M.2 2280 PCIe Gen 3 x2 slots Compatible with NVMe SSD PCIe Gen 3 and above. Please refer |
| SSD Cache Acceleration Support | Supported |
| GPU pass-through | Supported |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
| 5 Gigabit Ethernet Port (5G/2.5G/1G/100M) | Optional via PCIe expansion card |
| 10 Gigabit Ethernet Port | Optional via PCIe expansion card |
| Wake on LAN (WOL) | Supported |
| Jumbo Frame | Supported |
| PCIe Slot | 2 Slot 1: PCIe Gen 4 x16 Slot 2: PCIe Gen 3 x2 Card dimensions for PCIe slot 1~Slot 2:185 x 68.9 x 18.76 mm / 7.28 x 2.71 x 0.74 inches. Wider cards can be installed if the next PCIe slot will not be used. |
| USB 3.2 Gen 1 port | 1 |
| USB 3.2 Gen 2 (10Gbps) Port | 1 x Type-C USB 3.2 Gen 2 10Gbps 1 x Type-A USB 3.2 Gen 2 10Gbps |
| HDMI™ Output | 1, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz) |
| Form Factor | Tower |
| LED Indicators | HDD 1-4, Status, LAN, USB port, M.2 port |
| LCD Display/ Button | Supported |
| Buttons | Power, Reset, USB Copy |
| Dimensions (HxWxD) | 180.2 × 199.3 × 279.6 mm Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
| Weight (Net) | 6.1 kg |
| Weight (Gross) | 7.25 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27°C (80.6˚F) |
| Power Supply Unit | 250W, 100-240V |
| Power Consumption: HDD Sleep Mode | 34.906 W |
| Power Consumption: Operating Mode, Typical | 78.574 W Tested fully populated with WD10EFRX hard drives. |
| Fan | System fan: 1 x 120mm, 12VDC CPU fan: 1 x 60mm, 12VDC |
| System Warning | Buzzer |
| Kensington Security Slot | Supported |
| Standard Warranty | 3 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 700 |
Frequently asked questions about the QNAP TVS-h474-PT-8G
What is the QNAP TVS-h474-PT-8G?
It is a 4-bay QuTS hero NAS supplied with an Intel Pentium Gold G7400 processor and 8GB DDR4 memory.
Can the memory be expanded?
The supplied source lists 8GB installed as one 8GB module and a maximum of 64GB across two SODIMM slots.
Which drives are listed as compatible?
The source lists 3.5-inch SATA hard drives and 2.5-inch SATA solid-state drives.
What M.2 slots are included?
Two M.2 2280 PCIe Gen 3 x2 slots are listed, compatible with NVMe SSD PCIe Gen 3 and above.
What networking is built in?
The supplied specification lists two 2.5GbE ports. Faster 5GbE and 10GbE are optional via PCIe expansion.
Does it include Thunderbolt connectivity?
Thunderbolt ports are not listed in the supplied specification.
What is the warranty period?
The source provides the value 3 but no unit, so the warranty duration cannot be confirmed.
