8-bay QuTS hero NAS with 10GbE
QNAP TVS-H874X-I9-64G QuTS hero NAS
An eight-bay ZFS-based NAS with a 16-core Intel Core i9 processor, 64GB DDR4 memory, dual 10GBASE-T and dual 2.5GbE connectivity, plus M.2 NVMe and PCIe Gen 4 expansion.
ZFS-based storage for demanding business workflows
The QNAP TVS-H874X-I9-64G runs the ZFS-based QuTS hero operating system and is positioned for mission-critical file services, virtualisation, collaborative video editing, backup and recovery. Its supplied feature set combines inline deduplication and compression, snapshots, real-time SnapSync, M.2 NVMe SSD caching, hardware-accelerated transcoding and flexible PCIe Gen 4 expansion.
Key features and benefits
ZFS data services
QuTS hero supplies inline data deduplication and compression, snapshots, real-time SnapSync and SSD optimisation.
High-speed networking
Dual 10GBASE-T and dual 2.5GbE ports support bandwidth-demanding transfer, backup, multimedia and virtualisation workloads.
M.2 NVMe flexibility
Two M.2 2280 PCIe Gen 4 x4 slots support NVMe SSD caching and the supplied Edge TPU use case.
PCIe Gen 4 expansion
Two PCIe slots support the supplied network-adapter, QM2-card and entry-level graphics-card options.
Virtual machines and containers
The supplied platform positioning includes hosting multiple virtual machines and containers with optimised resource use.
AI and media acceleration
Intel OpenVINO, Intel UHD Graphics 770 and hardware-accelerated transcoding support the supplied image-recognition and media workflows.
Who is the QNAP TVS-H874X-I9-64G best for?
A strong choice for
- Businesses running shared file, backup and recovery services
- Virtualisation and container workloads based on the supplied positioning
- Collaborative video-editing environments using high-speed networking
- Teams needing built-in 10GbE and 2.5GbE connectivity
- Deployments that can use M.2 NVMe caching and PCIe expansion
Consider another model if you need
- More than eight internal SATA drive bays
- System memory above the supplied 64GB maximum
- A rackmount rather than tower form factor
- A configuration that does not require the supplied 10GbE connectivity
Key specifications
- CPU
- Intel Core i9 16-core (8P+8E) / 24-thread processor
- System memory
- 64GB SODIMM DDR4 (2 × 32GB); maximum 64GB
- Drive bays
- 8 × 3.5-inch SATA 6Gb/s, 3Gb/s
- Drive compatibility
- 3.5-inch SATA HDD; 2.5-inch SATA SSD
- M.2 slots
- 2 × M.2 2280 PCIe Gen 4 x4; compatible with NVMe SSD PCIe Gen 3 and above
- Networking
- 2 × 10GBASE-T; 2 × 2.5GbE
- PCIe slots
- 1 × PCIe Gen 4 x16; 1 × PCIe Gen 4 x4
- USB
- 1 × USB-C 3.2 Gen 2; 2 × USB-A 3.2 Gen 2
- HDMI
- 1 × HDMI 1.4b, up to 4096 × 2160 at 30Hz
- Dimensions
- 180.2 × 329.3 × 279.6 mm, excluding foot pad
- Net weight
- 7.34 kg
- Standard warranty
- 3 (unit not specified in supplied source)
Full technical specifications
View all supplied technical specifications
| CPU | Intel® Core™ i9 16-core (8P+8E) /24-thread Processor |
|---|---|
| CPU Architecture | 64-bit x86 |
| Graphic Processors | Intel® UHD Graphics 770 |
| Floating Point Unit | Supported |
| Encryption Engine | Supported (AES-NI) |
| Hardware-accelerated Transcoding | Supported |
| System Memory | 64 GB SODIMM DDR4 (2 x 32 GB) |
| Maximum Memory | 64 GB ( 2 x 32 GB) |
| Memory Slot | 2 x SODIMM DDR4 |
| Flash Memory | 5GB (Dual boot OS protection) |
| Drive Bay | 8 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-swappable | Supported |
| M.2 Slot | 2 x M.2 2280 PCIe Gen 4 x4 slots Compatible with NVMe SSD PCIe Gen 3 and above. |
| SSD Cache Acceleration Support | Supported |
| GPU pass-through | Supported |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
| 10 Gigabit Ethernet Port | 2 x 10GBASE-T |
| Wake on LAN (WOL) | Supported |
| Jumbo Frame | Supported |
| PCIe Slot | 2 Slot 1: PCIe Gen 4 x16 Slot 2: PCIe Gen 4 x4 *Slot 1 is preinstalled with a 10GbE network adapter. Card dimensions for PCIe slot 1~Slot 2:185 x 131.15 x 18.76 mm / 7.28 x 5.16 x 0.74 inches. Wider cards can be installed if the next PCIe slot will not be used. |
| USB 3.2 Gen 2 (10Gbps) Port | 1 x Type-C USB 3.2 Gen 2 10Gbps 2 x Type-A USB 3.2 Gen 2 10Gbps |
| HDMI™ Output | 1, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz) |
| Form Factor | Tower |
| LED Indicators | HDD 1-8, Status, LAN, USB port, M.2 port |
| LCD Display/ Button | Supported |
| Buttons | Power, Reset, USB Copy |
| Dimensions (HxWxD) | 180.2 × 329.3 × 279.6 mm Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
| Weight (Net) | 7.34 kg |
| Weight (Gross) | 8.99 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit | 350W (PWR-PSU-350W-DT01), 100-240V |
| Power Consumption: HDD Sleep Mode | 72.331 W |
| Power Consumption: Operating Mode, Typical | 96.247 W Tested fully populated with WD10EFRX hard drives. |
| Fan | System fan: 2 x 120mm, 12VDC CPU fan: 1 x 60mm, 12VDC |
| System Warning | Buzzer |
| Kensington Security Slot | Supported |
| Standard Warranty | 3 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 3500 |
Frequently asked questions about the QNAP TVS-H874X-I9-64G
What is the QNAP TVS-H874X-I9-64G?
The QNAP TVS-H874X-I9-64G is an eight-bay QuTS hero NAS with an Intel Core i9 processor, 64GB DDR4 memory, dual 10GbE and dual 2.5GbE ports.
How many drive bays does the QNAP TVS-H874X-I9-64G have?
It has eight 3.5-inch SATA 6Gb/s, 3Gb/s drive bays.
Which drives are supported by the QNAP TVS-H874X-I9-64G?
The supplied specification lists 3.5-inch SATA hard drives and 2.5-inch SATA solid state drives for the 3.5-inch bays.
How much memory is installed in the QNAP TVS-H874X-I9-64G?
It includes 64GB DDR4 memory as two 32GB SODIMMs. The supplied maximum is 64GB.
What networking is built into the QNAP TVS-H874X-I9-64G?
It includes two 10GBASE-T ports and two 2.5GbE ports supporting 2.5G, 1G, 100M and 10M speeds as supplied.
Does the QNAP TVS-H874X-I9-64G include M.2 slots?
Yes. It includes two M.2 2280 PCIe Gen 4 x4 slots, with compatibility stated for NVMe SSD PCIe Gen 3 and above.
Can the QNAP TVS-H874X-I9-64G run virtual machines and containers?
Yes. Hosting multiple virtual machines and containers is included in the supplied product positioning.
What is the warranty for the QNAP TVS-H874X-I9-64G?
The supplied Standard Warranty field contains only the value 3 and does not state a unit. Confirm the applicable warranty period before publishing or purchasing.
