1U rack-mount NAS with (4) 2.5/3.5" HDD bays and (2) M.2 NVMe SSD cache slots, delivering faster access, lower latency, and high-availability 10 Gbps networking for large-scale file storage and sharing.
Specification
Overview
-
Dimensions: 442.4 x 400 x 43.7 mm (17.4 × 15.7 × 1.7")
-
Storage Capacity: (4) 3.5" drive bays / (2) M.2 NVMe bays
-
Networking Interface: (2) 10G SFP+ (10G/1G), (1) GbE RJ45 (1G/100M/10M)
-
Power Redundancy: ✓
-
Form Factor: Rack mount (1U)
Hardware
-
Hard Drive Capacity: (4) 2.5/3.5" HDD / SSD support
-
M.2 Support: (2) M.2 NVMe SSD support
-
Max. Power Budget for Drives: 125W
-
Max. Power Consumption: 150W
-
Power Method:
(1) Universal AC input, 100—240V AC, 3A Max., 50/60 Hz
(1) USP-RPS DC input, 11.5V DC, 13.91A -
Power Supply: AC/DC, internal, 150W
-
Processor: Quad-Core ARM® Cortex®-A57 at 2.0 GHz
-
Memory: 8 GB
-
Management: Ethernet
-
RF Interface: Bluetooth 4.1
-
Weight: 6.7 kg (14.8 lb)
-
Enclosure Material: SGCC steel
-
Mount Material: SGCC steel
-
LEDs: Ethernet ✓ / SFP+ ✓ / HDD ✓ / RPS ✓ / System ✓
-
Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
-
Ambient Operating Humidity: 5 to 95% noncondensing
-
NDAA Compliant: ✓
-
Certifications: FCC, CE, IC
